Square Direct Weld Jack w/ Footplate - Drop Leg - Topwind - 29" Lift - 7,000 lbs

Weld-on jack has a retracted height of 24-1/4" and an extended height of 39-1/2". Square design provides superior side-load support. Offers 15-1/4" of screw travel and 13-3/4" of drop leg travel. Includes foldaway topwind handle.

Features:

Utility jack lets you raise and lower your trailer
Ideal for agricultural and commercial applications
Square jack provides more side-load capacity than round-tube jacks
Topwind handle has a claw grip for comfortable, easy cranking
Easily folds away for storage
Drop leg allows for increased lift and saves time when raising or lowering
Pin and clip holds leg at desired location
Effortless greasing with built-in grease zerk
Black powder coated outer tube
Zinc finished inner tube, footplate, and handle for corrosion resistance
Welded-on footplate minimizes sinking in soft ground
Weld-on installation

Specs:

Height (from bottom of foot to top of handle mount):
24-1/4" Retracted
39-1/2" Extended
Total lift: 29"
Screw travel: 15-1/4"
Drop leg travel: 13-3/4"
Lift capacity: 7,000 lbs
Support capacity: 8,000 lbs
Outer tube width: 2-1/4"
Inner
